Optical cabling

Recent high-speed protocols for optical cabling have triggered the development of new types of optical fibers and their new categorization. The initial categorization of fibers was based on glass core/cladding diameter: 50/125 μm, 62,5/125 μm or 9/125 μm. The latest fibers now have different transmission characteristics in spite of the same glass geometry. International standardization has therefore introduced a new classification based on the performance level of the fiber. The diagram bellow illustrates a relationship between the initial categorization and the new categories defined by standards:

2. The selection of performance category for fiber optical cabling.

Performance level is determined by the maximum transmission speed. Protocols ensuring these transmission speeds are supported in each category over different channel lengths. When choosing optical cabling, it is necessary to keep in mind the desired transmission speed and the maximum channel length (the longest segment of cabling). The diagram below illustrating standardized transmission protocols (excluding proprietary applications) used in structured cabling aims to simplify the selection of a suitable optical fiber:



3. Colour coding of components for performance category identification

Listed colour coding complies with requirements of ISO/IEC 11801: 2017 international standard or best practices.
