| Standard temperature range (installation) | -30°C to +40°C |
| Standard temperature range (operation) | -40°C to +70°C |
| Min. bending radius (installation) | 116 mm |
| Min. bending radius (operation) | 58 mm |
| Max. tensile load (installation) | 2000 N (200 kg) |
| Outer cable diameter | 5,8 mm |
| Weight | 40 kg / km |
| Number of tubes x number of fibers | 1 x 24 |
| Reaction to fire | Eca |
| Fire safety | flame retardant, low smoke, zero halogen, non-corrosive |
The determination of Reaction to Fire Class Performance of this cable has been performed by Product Certification Body notified by European Commision, which also carries out the assessment and verification of constant performance (AVCP) in the System 3.
25-Year System Warranty
12 fibers armoured fire-resistant universal central loose tube cable, 180 min. at 750°C, Euroclass B2ca - s1, d1, a1, OS2 9/125 μm (ITU-T G.652.D)
24 fibers armoured fire-resistant universal central loose tube cable, 180 min. at 750°C, Euroclass B2ca - s1, d1, a1, OS2 9/125 μm (ITU-T G.652.D)
12 fibers universal central loose tube cables, Euroclass B2ca - s1, d1, a1, OM3 50/125 μm
12 fibers universal central loose tube cables, Euroclass B2ca - s1, d1, a1, OS2 9/125 μm (ITU-T G.652.D)
24 fibers universal central loose tube cables, Euroclass B2ca - s1, d1, a1, OS2 9/125 μm (ITU-T G.652.D)
12 fibers central loose tube indoor cable, B2ca- s1, d1, a1, OS2 9/125 μm, (ITU-T G.652.D)
